Ktm 690 Smr 2013
KTM 690 SMC-R
| Make Model | KTM 690 SMC-R |
| Year | 2012 - 13 |
| Engine | Four stroke, single Cylinder. SOHC, 4 Valve |
| Capacity | 690 cc / 39.9 cu-in |
| Bore x Stroke | 102 x 84.5 mm |
| Cooling System | Liquid Cooled |
| Compression Ratio | 12.5:1 |
| Induction | Keihin EFI with EPT (Electr. Power Throttle) |
| Ignition | Kokusan DC-CDI |
| Starting | Electric |
| Clutch | APTC multi-disc wet clutch, hydraulically operated |
| Max Power | 49 kW / 65.7 hp @ 7500 rpm |
| Max Torque | 68 Nm / 50.1 lb-ft @ 6000 rpm |
| Transmission | 6 Speed |
| Final Drive | Chain 5/8 x 1/4" X Ring |
| Primary Drive | 36:79 |
| Final Ratio | 16:40 |
| Frame | Chromium-Molybdenum trellis frame, powder coated, Aluminium Sub frame, aluminium, tapered, � 28/22 mm handlebar. |
| Front Suspension | WP 48mm Upside-down forks, |
| Front Wheel Travel | 250 mm / 9.8 in |
| Rear Suspension | WP-Monoshock with Pro-Lever linkage, |
| Rear Wheel Travel | 250 mm / 9.8 in |
| Front Brakes | Single 320mm disc |
| Rear Brakes | Single 240mm disc |
| Front Tyre | 120/70 -ZR17 |
| Rear Tyre | 160/60 -ZR17 |
| Steering Head Angle | 63� |
| Wheelbase | 1480 mm / 58.2 in |
| Seat Height | 890 mm / 35 in |
| Ground Clearance | 270 mm / 10.6 in |
| Dry Weight | 139 kg / 306.4 lbs |
| Fuel Capacity | 12 Litres / 3.1 gal |
NO FAT, ONLY MUSCLES
What isn�t there won�t weigh you down � that is the philosophy of the 690 SMC R. A brawny single, a rugged frame, draped with only the most essential components � that is all it takes for great fun on road and track. And the way to achieve a sensational dry weight of less than 140 kilos. Even the tubes in the tires are discarded thanks to specially developed wire wheels with airtight beds.
The weight reduction thusly achieved lets the fully adjustable WP suspension components, once again optimised for MY2012, do their job even more diligently. Small wonder that the new LC4 power plant from the Duke R with even greater power reserves an easy time propelling this hard core Supermoto. Carried over from the Enduro, the perfectly balanced layout with a self-supporting
polymer tail tank ensures that skilled riders can sling the 690 SMC R effortlessly into any corner. An adult toy for experts!
KTM 690 SMCR Features and Benefits
- Powerful LC4 1-cylinder, 4-stroke engine with electronic fuel injection, balancer shaft, APTC anti-hopping clutch and 6-speed gearbox
-Max. output: 49 kW/67 hp, emissions: Euro 3
-Light steel trellis frame with innovative, die-cast swingarm and self-supporting polymer tail tank
-New, ergonomically optimised seat with increased comfort
-New, fully adjustable WP suspension with revised spring rates and optimised front/rear weight distribution for even greater agility
-High quality Brembo four-pot front brake system
New Continental SportAttack SM tires with outstanding grip
Tubeless wire wheels developed by KTM
New, dynamic spoiler line
Very low weight of only 139 kg
